M.A.S.S. Storage Drawer – 6 Inch (5×3 Pattern)

Important This a 5×3 pattern drawer. It will not be full-column width in the JL or JK. This is intended to take up less space (left to right) than our normal 6×4 drawers. Please visit the product page for the MASS Platform that corresponds to your vehicle for more information on our grid pattern and the reasons behind it. Interior Dimensions: 12.5″ wide (319) 23.6″ deep (600mm) 6″ tall (152mm) Exterior Dimensions: Height: 7″ (178mm) Depth: 25.8″ (655mm) – tip of slide handles to back of drawer Width: 14.5″ (367mm) Features: 5052 aluminum construction Ships with two removable dividers that can be bolted into place if needed 1/8″ (3mm) gap below each divider so you can run a single piece of drawer liner below them Two locking drawer sliders (one on each side) Zinc-plated steel hardware and nylon locking fasteners HD MASS Connectors Use HD MASS Connectors when stacking additional MASS modules on top of this drawer or when mounting the drawer to a standard MASS Platform. They are not needed with MASS Platforms or Modules since those already include the connection points. Because these drawers are used in many custom installs, the connectors are sold separately. You can add them to your order using the Frequently Purchased Together box above. We recommend four HD MASS Connectors to attach this drawer to a MASS Platform. Learn More Important Powder Coating Note Powder coating is a manual process done by humans and may take some time. When you purchase powder coated products from AAL, we coat them for your order. Occasionally, that means delays with non-standard colors, resprays for less-than-perfect conditions, etc. We have a very high standard with powder coated products. We will work to get your parts coated in the best condition possible before they leave the building. Please visit our Powder Coating Page for more info.
